ATS UPVC Borewell Pipes
Smooth Water Flow
High Tensile Strength
Long Life Durability
Description
Benefits
Applications
Installation
ATS UPVC Borewell Pipes are engineered to provide a highly efficient and durable solution for underground water extraction. Our range includes comprehensive solutions such as Borewell Casing Pipes (Shallow, Medium, Deep, and Extra Deep) and Column Pipes (Schedule 40 & 80) designed to withstand the tough conditions of deep-well environments.
Certifications & Standards
Our borewell and column pipes are proudly certified by ISO 9001:2015 and Pakistan Standards, conforming to international specifications like BS-3505 and ASTM D-1785. This ensures uncompromising quality and safety for drinking water extraction.
Key Advantages
- Smooth Water Flow: The extremely smooth inner surface minimizes friction, which increases water discharge capacity and significantly reduces the energy consumption of submersible pumps.
- High Tensile Strength: Specially manufactured to bear the immense hanging weight of submersible pumps and deep water columns without bending or breaking.
- Long Life Durability: 100% resistant to underground soil chemicals, rust, and corrosion. Unlike MS/GI pipes, these do not scale or decay, ensuring a lifespan of decades.
- Lightweight & Hygienic: Easy to transport and handle. The food-grade UPVC material prevents bacterial growth, keeping your water safe and clean.
Where to use ATS Borewell Pipes
Built for reliability in deep-earth conditions, these pipes are ideal for:
- Agricultural Tube-wells: Heavy-duty water extraction for irrigation across farms and fields.
- Domestic Water Supply: Clean and safe borewell setups for homes, housing societies, and apartment complexes.
- Industrial Use: High-capacity groundwater extraction for factories, cooling plants, and commercial facilities.
- Rainwater Harvesting: Can be utilized in deep recharge wells to replenish underground water levels.
Installation Guidelines
Proper installation ensures the safety of the pump and the longevity of the borewell:
- Step 1: Ensure the drilled bore is perfectly straight and clear of debris before lowering the casing or column pipes.
- Step 2: Use a proper tripod stand, chain pulley, and clamps. Never drop the pipes directly into the bore.
- Step 3: For threaded column pipes, ensure the threads are clean. Tighten the joints securely but avoid over-tightening with heavy wrenches to prevent thread damage.
- Step 4: Check that the submersible pump is securely attached to the bottom-most pipe before lowering the assembly.
UPVC BOREWELL CASING PIPES
| Nominal Size (Inches) | Mean Outside Diameter (mm) | B Class | C Class | D Class | E Class | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| Wall Thickness (mm) | Wall Thickness (mm) | Wall Thickness (mm) | Wall Thickness (mm) | |||||||
| Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | |
| 1.0" | 33.4 | 33.7 | - | - | - | - | - | - | 2.2 | 2.7 |
| 1¼" | 42.1 | 42.4 | - | - | - | - | 2.2 | 2.7 | 2.7 | 3.2 |
| 1½" | 48.1 | 48.4 | - | - | - | - | 2.5 | 3.0 | 3.1 | 3.7 |
| 2.0" | 60.2 | 60.5 | - | - | 2.5 | 3.0 | 3.1 | 3.7 | 3.9 | 4.5 |
| 2½" | 75.0 | 75.3 | - | - | 3.0 | 3.5 | 3.9 | 4.5 | 4.3 | 5.5 |
| 3.0" | 88.7 | 89.1 | 2.9 | 3.4 | 3.5 | 4.1 | 4.6 | 5.3 | 5.7 | 6.6 |
| 4.0" | 114.1 | 114.5 | 3.4 | 4.0 | 4.5 | 5.2 | 6.0 | 6.9 | 7.3 | 8.4 |
| 5.0" | 140.0 | 140.4 | 3.8 | 4.4 | 5.5 | 6.4 | 7.3 | 8.4 | 9.0 | 10.4 |
| 6.0" | 168.0 | 168.5 | 4.5 | 5.2 | 6.6 | 7.6 | 8.8 | 10.2 | 10.8 | 12.5 |
| 7.0" | 193.0 | 194.0 | 5.2 | 6.0 | 7.7 | 8.9 | 10.1 | 11.7 | 12.4 | 14.3 |
| 8.0" | 218.8 | 219.4 | 5.3 | 6.1 | 7.8 | 9.0 | 10.3 | 11.9 | 12.6 | 14.5 |
| 10.0" | 272.6 | 273.4 | 6.6 | 7.6 | 9.7 | 11.2 | 11.8 | 14.8 | 15.7 | 18.1 |
| 12.0" | 323.4 | 324.3 | 7.8 | 9.0 | 11.5 | 13.3 | 15.2 | 17.5 | 18.7 | 21.6 |
| 14.0" | 355.0 | 356.0 | 8.5 | 9.8 | 12.6 | 14.5 | 16.7 | 19.2 | 20.5 | 23.6 |
| 16.0" | 405.9 | 406.9 | 9.7 | 11.2 | 14.5 | 16.7 | 19.0 | 21.9 | 23.4 | 27.0 |
| 18.0" | 456.7 | 457.7 | 11.0 | 12.7 | 16.3 | 18.8 | 21.4 | 24.6 | - | - |
UPVC BS 3505 STANDARD PIPES (SCH 40)
| Nominal Size (Inches) | Mean Outside Diameter (mm) | Schedule 40 | |||
|---|---|---|---|---|---|
| Wall Thickness (mm) | Working Pressure PSI @ 23°C | ||||
| Min | Max | Min | Max | ||
| 1" | 33.4 | 33.4 | 3.38 | 3.89 | 450 |
| 1-1/4" | 42.16 | 42.16 | 3.56 | 4.07 | 370 |
| 1-1/2" | 48.28 | 48.28 | 3.68 | 4.19 | 330 |
| 2" | 60.32 | 60.32 | 3.91 | 4.42 | 280 |
| 2-1/2" | 73.02 | 73.02 | 5.16 | 5.77 | 300 |
| 3" | 88.9 | 88.9 | 5.49 | 6.15 | 260 |
| 4" | 114.3 | 114.3 | 6.02 | 6.73 | 220 |
| 5" | 141.3 | 141.3 | 6.55 | 7.34 | 198 |
| 6" | 168.28 | 168.28 | 7.11 | 7.97 | 180 |
| 8" | 219.08 | 219.46 | 8.18 | 9.17 | 160 |
| 10" | 273.05 | 273.43 | 9.27 | 10.39 | 140 |
| 12" | 323.85 | 324.23 | 10.31 | 11.55 | 130 |
| 14" | 355.6 | 355.98 | 11.1 | 12.45 | 130 |
| 16" | 406.4 | 406.88 | 12.7 | 14.22 | 130 |
| 18" | 457.2 | 457.2 | - | - | - |
UPVC BS 3505 STANDARD PIPES (SCH 80)
| Nominal Size (Inches) | Mean Outside Diameter (mm) | Schedule 80 | |||
|---|---|---|---|---|---|
| Wall Thickness (mm) | Working Pressure PSI @ 23°C | ||||
| Min | Max | Min | Max | ||
| 1" | 33.4 | 33.4 | 4.55 | 5.08 | 630 |
| 1-1/4" | 42.16 | 42.16 | 4.85 | 5.43 | 520 |
| 1-1/2" | 48.28 | 48.28 | 5.08 | 5.69 | 470 |
| 2" | 60.32 | 60.32 | 5.54 | 6.2 | 400 |
| 2-1/2" | 73.02 | 73.02 | 7.01 | 7.85 | 420 |
| 3" | 88.9 | 88.9 | 7.62 | 8.53 | 370 |
| 4" | 114.3 | 114.3 | 8.56 | 9.58 | 320 |
| 5" | 141.3 | 141.3 | 9.52 | 10.66 | 290 |
| 6" | 168.28 | 168.28 | 10.97 | 12.29 | 280 |
| 8" | 219.08 | 219.46 | 12.7 | 14.22 | 250 |
| 10" | 273.05 | 273.43 | 15.06 | 16.86 | 230 |
| 12" | 323.85 | 324.23 | 17.45 | 20.25 | 230 |
| 14" | 355.6 | 355.98 | 19.06 | 21.35 | 220 |
| 16" | 406.4 | 406.88 | 21.41 | 23.98 | 220 |
| 18" | 457.2 | 457.2 | - | - | - |
Ready to Upgrade Your Pumping System?
Whether you need casing pipes for shallow wells or heavy-duty column pipes for deep water extraction, ATS provides the highest quality at wholesale rates.
